1080p Wired Bird Box Camera with 20m Cable & HDMI Adapter

Camera origin: Designed in Britain and manufactured overseas.

Watch and listen to nesting birds with this Green Feathers 1080p wired bird box and wildlife camera. Its built-in microphone captures calls and rustles, while the supplied 20-metre RCA cable and AV-to-HDMI converter provide a wired connection for viewing on a compatible television.

The camera requires mains power and a cable connection, not WiFi or an app. A bird box and television are not included. The AV-to-HDMI converter is included with this pack, rather than an optional extra.

Detailed images and nest sounds

The camera supports 1920 × 1080 video at 25 frames per second. Its Starlight sensor supports viewing in low light, with infrared night vision for dark conditions. A wide-angle lens helps capture more of the space inside an enclosed habitat.

The lens has no manual focus adjustment. Position and test the camera before completing installation to achieve a useful view of the nest.

Weather-resistant design

The camera is rated IP65 for outdoor weather resistance. Install it and protect the cable and power connections according to the supplied instructions.

Video connections and controls

The camera supports switchable AHD, TVI, CVI and CVBS video formats. Follow the camera and converter instructions to select a compatible mode for your viewing equipment. The available output modes do not mean every connection carries the same image resolution.

Image controls include brightness, exposure, gain, contrast, sharpness, colour, noise reduction and wide dynamic range.

Specifications

• Camera dimensions: 54 × 44 × 52mm
• Sensor/chipset: 1/2.8-inch NVP2441 + IMX307
• Video format: PAL/NTSC
• Effective pixels: 1920 × 1080
• Frame rate: 1080p at 25fps
• Minimum illumination: 0.0001 lux at F1.2 with AGC on; 0 lux with infrared
• Shutter: automatic
• Day/night modes: EXT (default), Auto, Colour and Black & White
• Synchronisation: internal
• Video output: switchable AHD/TVI/CVI/CVBS
• White balance: ATW/MWB
• Audio: built-in microphone
• Weather-resistance rating: IP65
• Operating temperature: −20°C to +60°C
• Working humidity: below 90%
• Power input: DC 12V, 1A
• Camera weight: 0.2kg
• Power consumption: 0.6W with IR off; 0.9W with IR on

What's included

• 1 1080p HD wired bird box camera
• UK mains power supply
• 1 20-metre RCA cable
• 1 AV-to-HDMI converter

Installation

Fit the camera in your chosen habitat, run the supplied cable to your viewing location and connect the power supply. Use the included converter to connect to a compatible TV's HDMI input, following the camera and converter instructions. Test the complete setup before fixing the equipment in place.
